Description

Features:

• Beam Flange Thickness: 0.25” – 1.25”
• Beam Flange Width Range: 3.5” – 14”

Metal Materials:

• Min. Breaking Strength: 5,000 lbs.
• Adjustable Hooks: Aluminum
• Swivel Ring: Steel
• Rod: Aluminum
• Notches: Aluminum
• Push Button: Steel

Weight:

3.5 lbs.

User Weight Capacity:

ANSI 130-310 lbs. (140.6kg)

Metal Materials:

• Min. Breaking Strength: 3,000 lbs.
• Max Arresting Distance: 42”
• Max Arresting Force: 1,800 lbs.

Size:

Part #	Size
BEAM01	3.5”-14”

Standards:

Meets or Exceeds: ANSI Z359.18-2017 Type A



---

Resources

Technical Data Sheet



User Instruction Manual
