Description

Features:

• Yellow Full body harness with 3 adjustment points: chest strap & leg straps
• Dorsal D-ring with SRL Plate
• Additional D-rings: Side Positioning
• Adjustable mating buckle leg straps
• 2 lanyard keepers, breaking under 120 lbs.
• 2 fall indicators on the back torso straps

User Weight Capacity:

ANSI 130-310 lbs. (140.6kg)

Webbing:

• Width: 1.75”
• Material: 100% polyester
• Min Breaking Strength: 6,000 lbs.

Metal Materials:

• Dorsal D-ring
  Material: Forged Steel
  Min Breaking Strength: 5,000 lbs.
• Waist Side D-rings
  Material: Stamped Steel
  Min Breaking Strength: 5,000 lbs.
• Mating Buckles
  Material: Stamped Steel
  Min Breaking Strength: 4,000 lbs.

Size:

Part #	Size
H302	Universal Size (M-XL)

Standards:

Meets or Exceeds: ANSI Z359.11-2021



---
